Xfdiii 1.5L Lab Scale Mini Small Froth Flotation Cell Machine for Gold Copper Silver Lead Zinc Fluorite Lithium Nickel Ore

Basic Info.

Model NO.	XFDIII-1.5L
Material	Carbon Steel
Material Feature	Ware Resistant
Certification	ISO9001:2008
Energy Saving	Energy Saving
Warranty	1 Year
Color	Grey
Customized	Customized
Condition	New
After-sales Service	Yes
Speed of Scraper	15-30
Temperature	0-50
Feeding Size	0.25mm
Speed of Impeller	0-2800r/Min
Cell Capacity	0.5/0.75/1/1.5/3/8L
Transport Package	Nude Package
Specification	depends on model
Trademark	JXWKD
Origin	China
HS Code	8474100000
Production Capacity	200 Sets/Month

Packaging & Delivery

Package Size 80.00cm * 80.00cm * 90.00cm Package Gross Weight 88.000kg

Product Description

Laboratory Froth Flotation Machine

Product Application

XFDIII series laboratory flotation cell machine: It is our unique design among China.
Applied in mining, geology, metallurgy, building materials, chemical and other industrial laboratory flotation ore with a small amount.
Best for metal minerals like Gold, Silver, Copper, Lead, Zinc, Lithium, Nickel;
And graphite, sulfur, diamond, quartz, mica, feldspar and other non-metallic minerals and silicate minerals and fluorite, apatite, barite and other non-metallic salt minerals and potassium salt, rock salt and other soluble salt minerals.
Reduction of ash in fine coal and removal of fine pyrite from coal.
Advantages should let you know
1. Unique design among China. We are in stock!!!
2. Use inverter technology. Variable speed impeller, adjustable 0-2800 r/min, digital display.
3. Self-aerated, manually adjust the air volume, and can also be externally recharged, making it easier to generate froth, clear and stable display.
4. Equipped with a heater(250w), temperature control device to control, display flotation cell temperature at any time. Max 50 Celsius, digital display.
5. 0.5/0.75/1/1.5/3 and 8 L acrylic cells available.
6. Stainless steel flotation column, rubber impeller,automatic stainless steel scraper, no need manual.
7. Stainless steel tray for easy discharging.
8. 220V/50-60Hz single phase, durable 120w/250w motor.

Technical Parameters

Technical Parameters	Model
	XFDIII0.5	XFDIII0.75	XFDIII1.0	XFDIII1.5	XFDIII3.0	XFDIII8
cell capacity(L)	0.5	0.75	1	1.5	3	8
rotary speed of impeller(r/min)	0-2800					0-1400
impeller diameter (mm)	45		55	60	70	100
rotary speed of scraper(r/min)	15,30
size of feeding(mm)	0.25
motor power(w)	90					250
overall size(mm)	400*310*660		400*310*700		460*350*780
weight(kg)	30		35	43	50	80

Detailed Images

We do have more laboratory flotation cell machine for your reference.

Packaging & Shipping

Company Information

Jiangxi Victor International Mining Equipment Co.,Ltd is a large mineral processing manufacturer for 15 years history, with covering an area of 48,000 square meters and 20,000 square meters for workshop, with various large modernized machinery facilities, professional R&D team and installation team.

With 32% market share in China and the rest to overseas, already successfully exported to over 50 countries, such as USA, England, Australia, Brazil, Turkey, Italy, Russia, South Africa, Zimbabwe, Sudan, Ghana, Congo, Morocco, India,Indonesia, Malaysia, Philippines, Mongolia, Vietnam, Thailand etc.
Our goal is to provide one-stop service for you and assist you to solve all problems from investment to his return in the field of mining, including the preliminary mineral analysis, mineral processing test, engineering design, equipment debugging and technical training etc..
We are expert especially at mining separating and lab mining plant, main products as below:
Gold trommel wash plant
Shaking table
Spiral chute separator
Centrifugal gold concentrator
Jig separator machines
Waste recycling machine
Grinding and mill crusher
Flotation cell machine
Magnetic separator
Laboratory mining plant
